ShopMDITM
When Manual Input is Required for
Production Status, Maintenance, Gauge Measurements...
ShopMDITM part of an Integrated Family of ShopFloorManagerTM Modules
Supports Windows 10 TM & Windows 8 TM including Support for Windows' Server 2008/2010/2012/2019

ShopMDITM a ShopFloorManager TM Application that is used to Automate the Manual Entry of Critical Data from Programs created with ShopMonitor. This Time Sensitive Critical Data can include data from Production, Maintenance, Probe Measurements, Inspection, System State Data....

This Collected Data is immediately available for use by other ShopFloorManager Applications such as ShopReports, ShopCharts... ShopCharts is a Real-Time Interactive Application where Users can interrogate any of it's Displayed Events by a simply Zoom & Click on the Event!

Some examples of this Time Sensitive Critical Data that ShopMDITM can collect are Production/Cycle Counts, Production/Cycle Times, Production/Idle Times, Production/Cycle Start, Production/Cycle End, Probe Data, Inspection Data, Tool Changes, Feed Rate Override, Machine Hold, etc.

Note: Use ShopMDI to supplement Automated CNCs or if you can't use Macros with DPrints in N/C Files or your Machine Tools don't support DPrint!

ShopMDITM A Manual Data Inputting Application Supporting ShopMonitor Created Programs

ShopMDI is used for inputting Data using Tablets or Computers. Using Programs create with ShopMonitor you can record: Production Status, Probe Measurement, Maintenance Status, etc. Using ShopMDI you can collect data from Manual & Automated CNCs during normal Production, Maintenance or with non-Macro based CNCs.

Standard

ShopMDITM

ShopMDI TM supports any Monitoring Program created with ShopMonitor
  • Quality
  • Maintenance
  • OEE Categories
  • Production
  • More...
Unplanned Breaks - Medical Emergency (Example)
Note:

OEE calculations are an important metric for measuring how your company efficiently uses it's Assets. It provides data & values allowing you to analyze problems and to see how you efficiently utilize your Assets.

That is all and well but if this is the only metric that is produced, your Company is missing huge amounts of other Non-Production Data. This missed data can be helpful in providing real-time information to aid Managers & other Personnel to feel the pulse of their Shop!

What is meant by that? What if the OEE report is not detailed enough even though the times are correct. It would be helpful to have another more detailed Monitoring Program to dig much deeper into the OEE events of interest! ShopMonitor allows you to create such programs and classify these Programs in the same OEE categories of the Programs of interest.

ShopMDI'sTM Basics

ShopMDI'sTM Basics Include:
  • Manual Data Collection & Entry of any Existing ShopMonitor Program
  • User Automatically Guided During Initial Use
  • Supports User Defined Data Fields for Data Entry & Collection of almost any Type of Data
  • Collected Data used for Real-Time Event Status Display at Each Runtime Client Machine Status Window
  • Collected Data used for Real-Time Intelligent Charting (ShopCharts) with User Interrogation
  • Keeps an Ordered List of Data Submissions
  • Deploy on any Windows Client

Manual Entry of
Production, State...
Critical Data

ShopMDITM in Conjunction with ShopMonitor Supports:
  • Real-Time Access to Events Configured with ShopMonitor
  • Events Accessed allow Manually Entry of Production Starts & Ends, Probe Data, etc.)
  • Processing these Machine/Production/Probe Events in Real-Time
  • Real-Time Storage of this Critical Data in ShopFloorManager's database
  • Generating Configurable Production, Maintenance, Measurement... Reports
  • Real-Time Display & Access of Critical Shop Floor Metrics
  • Much more....

Note: ShopMDI can Access any "Event Program" created with ShopMonitor and support manual entry of all the "Event Program" Data for use by other ShopFloorManager Programs such as ShopCharts, ShopReports...

Collect, Create
And Display
Real-Time Events

ShopMDITM in Conjunction with ShopMonitor & ShopCharts Allows you To:
  • Collect, Create & Display Real-Time Production/Cycle Counts Events
  • Collect, Create & Display Real-Time Probe Measurement Events
  • Collect, Create & Display Real-Time State Data Events (Example: Maintenance)
  • Collect, Create & Display Real-Time Virtually any Event
  • Quality, Bad Part Counts
  • Much more....

Note: These Events can then be Accessed by ShopMDI for inputting the Event Data in the appropriate "Text" Fields for submitting to ShopMonitor'sTM Processing Engine.

Create Event
Reports With
Configurable Filters

ShopMDITM in Conjunction with ShopMonitor & ShopReports so You Can:
  • Create & Generate a User Configurable Production Event Reports
  • Create & Generate a User Configurable Session Activity Reports
  • Configure Reports for Generating Data by Machine and Data Item Reports
  • Configure Reports for Generating Data by Data Item and Machine Reports
  • Configure Reports for Generating Machine Utilization Chart Reports
  • Configure Reports for Generating & Display Real-Time Utilization 7-Day History Chart (ShopCharts)
  • Much more....

Save Current Filtered &
Report Template For
Single Click Reporting

ShopMDITM in Conjunction with ShopMonitor & ShopReports Allows you To:
  • Create Individual Event Report Templates
  • Save Individual Event Report Templates as Shared with Your Report Name
  • Save Individual Event Report Templates as Private with Your Report Name
  • Copy, Modify and Save an Existing Template to a New Template
  • Much more....

Note: This allows you to choose a Template/Report by simply clicking your saved Template and automatically generating your reports. Configure once for Single Click Reporting!

Real-Time Event
Status Displayed At Any
ShopFloorManager Client

ShopMDITMin Conjunction with ShopManagerRuntime & ShopCharts Allows you To:
  • Display the current Event being processed for the selected Machine in Real-Time
  • Select the Displayed List of Monitored Machine Tools at Each Client
  • Select a Different List of Monitored Machine Tools at Different Clients
  • Display a Green Light if a Machine is Running
  • Display a Red Light if a Machine is not Running

Note: This Real-Time Data Displayed can includes Manual Machine Name, Last Event Command, ShopNCFile, ShopNCFile Version, Status, Run, Idle, Elapsed Time, Cycle Count, Start Time, Last Event Time, Exceptions, Tool Number, Probe Val, Tool Number, Spindle Load, etc.

Real-Time Intelligent
Charting Displayed at
Any ShopRuntime

ShopMDITM in Conjunction with ShopRuntime, ShopMonitor & ShopCharts Allows you To:
  • From ShopRuntime Select "Show Machine Event Status" Icon to Display your Shop Floor's Status
  • Configure Which Machines' Status to Collect
  • Configure Which Machines' Status to Display
  • Select a Specific Machine(s), Manual or Automated, to Display Real-Time Intelligent Chart(s)
  • Display: Machine Name, Last Event, DNC File & Version, etc. Real-Time Charting
  • Select a Different List of Monitored Machine Tools at Different Clients
  • Much more....

Note: You can interactively click on the ShopCharts' Displayed Events and Retrieve all the Collected data for that Event!
